For a client I needed a way to draw a gradient in realtime generated from four points, on a mobile phone.  To produce an image like this, where the four gradient points can be moved in realtime:

I wanted to implement this using a shader, but after googling for a while I couldn’t find an existing implementation.



The problem is that I have the desired colours at four points, and need to calculate the colour at any other arbitrary point.



So we have three simultaneous equations (vectors in bold):

The key to solving this is to reduce the number of freedoms by setting .

Solving for gives us:

And solving for and :

so:

Defining:

Lets us now rewrite as:

Which written out for x and y is:

Now we have to consider the various different cases. If then we have:

Likewise if then we have:

Otherwise we are safe to divide by and so:

Which can be solved with the quadratic formula when A is not zero: (Note that only the positive solution makes physical sense for us, and we can assume )

and when A is zero (or, for computational rounding purposes, close to zero):

Math Summary

We can determine and with:

Implementation as a shader:

This can be implemented as a shader as following: (The following can be run directly on https://www.shadertoy.com for example)

void mainImage( out vec4 fragColor, in vec2 fragCoord )
{

    //Example colors.  In practise these would be passed in
    // as parameters
    vec4 color0 = vec4(0.918, 0.824, 0.573, 1.0); // EAD292
    vec4 color1 = vec4(0.494, 0.694, 0.659, 1.0); // 7EB1A8
    vec4 color2 = vec4(0.992, 0.671, 0.537, 1.0); // FDAB89
    vec4 color3 = vec4(0.859, 0.047, 0.212, 1.0); // DB0C36

    vec2 uv = fragCoord.xy / iResolution.xy;

    //Example coordinates.  In practise these would be passed in
    // as parameters
    vec2 P0 = vec2(0.31,0.3);
    vec2 P1 = vec2(0.7,0.32);
    vec2 P2 = vec2(0.28,0.71);
    vec2 P3 = vec2(0.72,0.75);

    vec2 Q = P0 - P2;
    vec2 R = P1 - P0;
    vec2 S = R + P2 - P3;
    vec2 T = P0 - uv;

    float u;
    float t;

    if(Q.x == 0.0 && S.x == 0.0) {
        u = -T.x/R.x;
        t = (T.y + u*R.y) / (Q.y + u*S.y);
    } else if(Q.y == 0.0 && S.y == 0.0) {
        u = -T.y/R.y;
        t = (T.x + u*R.x) / (Q.x + u*S.x);
    } else {
        float A = S.x * R.y - R.x * S.y;
        float B = S.x * T.y - T.x * S.y + Q.x*R.y - R.x*Q.y;
        float C = Q.x * T.y - T.x * Q.y;
        // Solve Au^2 + Bu + C = 0
        if(abs(A) < 0.0001)
            u = -C/B;
        else
	    u = (-B+sqrt(B*B-4.0*A*C))/(2.0*A);
        t = (T.y + u*R.y) / (Q.y + u*S.y);
    }
    u = clamp(u,0.0,1.0);
    t = clamp(t,0.0,1.0);

    // These two lines smooth out t and u to avoid visual 'lines' at the boundaries.  They can be removed to improve performance at the cost of graphics quality.
    t = smoothstep(0.0, 1.0, t);
    u = smoothstep(0.0, 1.0, u);

    vec4 colorA = mix(color0,color1,u);
    vec4 colorB = mix(color2,color3,u);
    fragColor = mix(colorA, colorB, t);
}

And the same code again, but formatted as a more typical shader and with parameters:

          uniform lowp vec4 color0;
          uniform lowp vec4 color1;
          uniform lowp vec4 color2;
          uniform lowp vec4 color3;
          uniform lowp vec2 p0;
          uniform lowp vec2 p1;
          uniform lowp vec2 p2;
          uniform lowp vec2 p3;
          varying lowp vec2 coord;

          void main() {
            lowp vec2 Q = p0 - p2;
            lowp vec2 R = p1 - p0;
            lowp vec2 S = R + p2 - p3;
            lowp vec2 T = p0 - coord;

            lowp float u;
            lowp float t;

            if(Q.x == 0.0 && S.x == 0.0) {
                u = -T.x/R.x;
                t = (T.y + u*R.y) / (Q.y + u*S.y);
            } else if(Q.y == 0.0 && S.y == 0.0) {
                u = -T.y/R.y;
                t = (T.x + u*R.x) / (Q.x + u*S.x);
            } else {
                float A = S.x * R.y - R.x * S.y;
                float B = S.x * T.y - T.x * S.y + Q.x*R.y - R.x*Q.y;
                float C = Q.x * T.y - T.x * Q.y;
                // Solve Au^2 + Bu + C = 0
                if(abs(A) < 0.0001)
                    u = -C/B;
                else
                    u = (-B+sqrt(B*B-4.0*A*C))/(2.0*A);
                t = (T.y + u*R.y) / (Q.y + u*S.y);

            }
            u = clamp(u,0.0,1.0);
            t = clamp(t,0.0,1.0);

            // These two lines smooth out t and u to avoid visual 'lines' at the boundaries.  They can be removed to improve performance at the cost of graphics quality.
            t = smoothstep(0.0, 1.0, t);
            u = smoothstep(0.0, 1.0, u);

            lowp vec4 colorA = mix(color0,color1,u);
            lowp vec4 colorB = mix(color2,color3,u);
            gl_FragColor = mix(colorA, colorB, t);
          }

Result

On the left is the result using smoothstep to smooth t and u, and on the right is the result without it.  Although the non-linear smoothstep is computationally-expensive and a hack, I wasn’t happy with the visual lines that resulted in not using it.
