Mars Rover Robot

This is an ongoing multi-year project.  I need to write this up properly, but I’ve got so much stuff that I’m going to attack this in stages.

Current Status

14 motors, controlled by a raspberry pi.  Arm doesn’t quite work yet.  Everything else works.

Front end – I wrote this in ReactJS, and it communicates with the robot via a websocket to RobotOS, using ‘rosbridge’.  Sorry it’s so pink – it uses infrared LEDs to work at night, but they are kinda overpowering.  Also sorry for the mess – I have two children…

React frontend

In the top left, the green circle is a ‘nipple’ – to let you move the rover about via webpage. Either via mouse or finger press.

In the top right, the xbox controller image shows what buttons are being pressed on an xbox controller, to control the robot. The xbox controller can either be connected to the rover, or connected to the PC / mobile phone – the webpage relays controller commands through to the rover.

Beneath the xbox controller is the list of running processes (“ros nodes”), with cpu and mem information.

Below that is the error messages etc.

Console UI

I’m strong believer in trying to make my projects ‘transparent’ – as in, when you connect, it should be obvious what is going on, and how to do things.

With that in mind, I always create nice colored scripts that show the current status.

Below is the output when I ssh into the raspberry pi.  It shows:

– Wifi status and IP address
– Currently running ROS Node processes, and their mem and cpu status.  Colored Green for good, Red for stopped/crashed.
– Show that ‘rosmon’ is running on ‘screen’ and how to connect to it.
– The command line shows the current git status

rover_putty

I put this script in git in two parts – the first is a bash script to source from bash, and the second is a python script to use ros to get the current status.

See those links for the source code.  I think that every ROS project can benefit from these.

Boogie Rocker Design

Ultrasonic Sensor

I played about with making a robot face.  I combined a Ultrasonic Sensor (HC-SR04) and NeoPixel leds.  The leds reflect the distance – one pixel per 10 of cm.

I’m wondering if I can do SLAM – Simultaneous Location And Mapping  with a single (or a few) very-cheap ultrasonic sensor. Well, the answer is almost certainly no, but I’m very curious to see how far I can get.

NOTE: This is an old design – from more than two years ago

face2

6DOF head tracking in python (Part 2 of Samurai Robot)

Samurai Robot Series:

  1. Part 1 – Hardware
  2. Part 2 – 6DOF head tracking in python



I wanted a simple way to track the movement and orientation of an object (In this case, my Samurai robot).  TrackIR’s SDK is not public, and has no python support as far as I know.

I looked at the symbols in dll that is distributed with the trackir app, and with some googling around on the function names, I could piece together how to use this API.

Here’s the result – my console program running in a window in the middle.  I have pressed ctrl+c after 70ms, to cancel, to give a better screenshot:trackir_screenshot

Implementation Details

Python lets you call functions in any .dll library pretty easily (although the documentation for doing so is pretty awful).  The entire code is approximately 500 lines, with half of that being comments, and I’ve put on github here:

https://github.com/johnflux/python_trackir

But here’s a high overview of the implementation:

  1. Query the Windows registry for where the TrackIR software is installed.
  2. Load the NPClient64.dll in that TrackIR software folder, using python ctypes.WinDLL (Note, I’m using 64 bit python, so I want the 64 bit library)
  3. Expose each function in the dll that we want to use.  This can get a bit cryptic, and took a bit of messing about to get right.  For example, there is a function in the dll ‘NP_StopCursor’, that in C would look like:
    int NP_StopCursor(void)

    This translates in python to:

    NP_StopCursor = ctypes.WINFUNCTYPE(ctypes.c_int)(
    ("NP_StopCursor", trackIrDll), ())

    where ‘NP_StopCursor’ is now a function that can then be called with:  NP_StopCursor().  See the trackir.py file for more, including on how to pass parameters which are data structures etc.

    Note: Python ctypes supports a way to mark a parameter as an ‘output’, but I didn’t fully understand what it was doing.  It seemed to just work, and appeared to automatically allocate the memory for you, but the documentation didn’t explain it, and I didn’t entirely trust that I wasn’t just corrupting random memory, so I stuck to making all the parameters input parameters and ‘new’ing the data structure myself.

  4. Create a graphical window and get its handle (hWnd), and call the functions in the TrackIR  .dll to setup the polling, and pass the handle along.  The TrackIR software will poll every 10 seconds ish to check that the given graphic window is still alive, and shutdown the connection if not.
  5. Poll the DLL at 120hz to get the 6DOF position and orientation information.

ROS Integration

I wanted to get this to stream 6DOF data to ROS as well, to open up possibilities such as being able to determine the position of a robot, or to control the robot with your head etc.

The easiest way is to run a websocket server on the linux ROS server, and send the data via ROS message via the websocket.

A good place to start: https://github.com/Sanic/ROSBridgeTestclient/blob/master/BSONTestClient.py

Samurai Robot: Part 1

Samurai Robot Series:

  1. Part 1 – Hardware
  2. Part 2 – 6DOF head tracking in python

I saw this for sale in a Christmas market for 500 yen (~$5 USD) and immediately bought it. My wife questioned my sanity, since it’s for “boy’s day” (It’s a “五月人形”) and we have no boys.

But, I could see the robotic potential!


Note: I have put the gold plated metal through an ultrasonic cleaner and buffed them with British Museum wax.  But I’m not sure how to remove the corrosion – please message me if you have any ideas.

Next step is to build a wooden skeleton to mount the motors:

Ul0dLoX

I’ve used 2 MG996 servo motors (presumably clones).

And a quick and dirty arduino program to move the head in a circular motion:


#include

Servo up_down_servo;     // create servo object to control a servo
Servo left_right_servo;  // create servo object to control a servo

int pos = 0;    // variable to store the servo position

void setup() {
  up_down_servo.attach(8);  // attaches the servo on pin 8 to the servo object
  up_down_servo.write(170); // Maximum is 170 and that's looking forward, and smallest is about 140 and that is looking a bit downwards

  left_right_servo.attach(9);  // attaches the servo on pin 9 to the servo object
  left_right_servo.write(170); // 155 is facing forward.  170 is looking to the left for him
  Serial.begin(115200);
  Serial.println("up_down, left_right");  // Output a CSV stream, showing the desired positions
}

void loop() {
  const float graduations = 1000.0;

  for (pos = 0; pos < graduations; pos++) {
    const float up_down_angle = 160+10*sin(pos / graduations * 2.0 * 3.1415);
    const float left_right_angle = 155+5*cos(pos / graduations * 2.0 * 3.1415);
    left_right_servo.write(left_right_angle);
    up_down_servo.write(up_down_angle);
    Serial.print(up_down_angle);
    Serial.print(",");
    Serial.println(left_right_angle);
    delay(15);
  }
}

And the result:

Jerky Movement

Unfortunately the movement of the head is extremely jerky.  to quantify this, lets track the position accurately.

To do so, I mounted a TrackIR:  3 small reflective markers, which are then picked up by a camera.  The position of the reflective markers are then determined, and the 6DOF position of the head calculated.

To actually log the data from TrackIR was tricky.  To achieve this, I used FreePIE – an application for ‘bridging and emulating input devices’.   It supports TrackIR as an input, and allows you to run a python function on input.

I wrote the following script to output CSV:

#Use Z to force flushing file to disk
import os
def update():
    # Note that you need to set the
    # curves for these to 1:1 in the TrackIR gui, which needs to be running
    # at the same time.
    yaw = trackIR.yaw
    pitch = trackIR.pitch
    roll = trackIR.roll
    x = trackIR.x
    y = trackIR.y
    z = trackIR.z
    csv_str = yaw.ToString() + "," + pitch.ToString() + "," + roll.ToString() +  "," + x.ToString()  + "," + y.ToString()  + "," + z.ToString() + "\n"
    #diagnostics.debug(csv_str)
    f.write(csv_str)
if starting:
    global f
    trackIR.update += update
    f = open("trackir output.csv","w")
    diagnostics.debug("Logging to:  " + os.path.realpath(f.name))
    f.write("yaw,pitch,roll,x,y,z\n")
if keyboard.getPressed(Key.Z):
    f.flush()
    diagnostics.debug("flushing")

And taped the head tracker like so:

A2iBzNH

Note 1: I also set the TrackIR response curves to all be 1:1 and disabled smoothing of the input. We want the raw data. Although I later realised that freepie exposes the raw data, so I could have just used that instead.

Note 2: If you enable logging in FreePIE, it outputs the log to “C:\Program Files (x86)\FreePIE\trackirworker.txt”

Note 3: For some reason, FreePIE is only updating the TrackIR readings at 4hz. I don’t know why – I looked into the code, but without much success. I filed a bug.

And here are the results:

trackir reported position against time xy

There is a lot of a jerkiness here.  This is supposed to look like a beautiful sinusoidal curve: sine_wave

To fix this, and make the movement smooth, we need to understand where this jerkiness comes from.

Source of jerkiness

A quick word about motivation:  For almost my entire life, I’ve wanted to build robots with smooth natural-looking movement, and I’ve hated the unnatural jerkiness that you often see.

A quick word about terminology:  ‘Jerkiness’ has a real technical meaning – it is the function of position over time, differentiated 3 times.  Since we are aiming for a circular movement, and since the 3rd order differential of a sinusoidal movement is still sinusoidal, even in the ideal situation there is still technically a non-zero jerk.  So here I mean jerkiness in a more informal manor.  I have previously written about, and written code for, motion planning with a guaranteed jerk of 0 when controlling a car, for which the jerkiness really must be minimized to prevent whiplash and discomfort.

We must understand how a servo works:

How a servo works

A servo is a small geared DC motor, a potentiometer to measure position, and a control circuit that presumably uses some basic PID algorithm to power the motor to try to match the potentiometer reading to the pulse width given on the input line:

To prevent the motor from ‘rocking’ back and forth around the desired value, the control circuit implements a ‘dead bandwith’ – a region in which it considers the current position to be ‘close enough’ to the given pulse.

For the MG996R servo that I’m using, the spec sheet says:


Note the ‘Dead band width’ of 5µs.  The servo moves about 130 degrees when given a duty cycle between 800µs to 2200µs.  NOTE:  This means that the maximum duty cycle is only about 10% of the PWM period.

So this means that we move approximately 10µs per degree: (2200µs – 800µs)/130° 10µs.

So our dead band width is approximately 0.5°.  Note that that means ±0.25°.

The arduino Servo::write(int angle) command takes an integer number of degrees, and by default is configured to 5µs per degree (2400µs – 544µs)/180° 10µs this means that we are introducing four times as much ‘jerkiness’ into our movement than we need to, simply from sloppy API usage.  (Numbers taken from github Servo.h code)

So lets change the code to use the four times as accurate:  Servo::writeMicroseconds(int microseconds)  which lets us specify the number of microseconds for the duty cycle:

#include

Servo up_down_servo;     // create servo object to control a servo
Servo left_right_servo;  // create servo object to control a servo

int pos = 0;    // variable to store the servo position

void servoAccurateWrite(const Servo &servo, float angle) {
  /* 544 default used by Servo object, but ~800 on MG996R) */
  const int min_duty_cycle_us = MIN_PULSE_WIDTH;
  /* 2400 default used by Servo object, but ~2200 on MG996R) */
  const int max_duty_cycle_us = MAX_PULSE_WIDTH;
  /* Default used by Servo object, but ~130 on MG996R */
  const int min_to_max_angle = 180;
  const int duty_cycle_us = min + angle * (max - min)/min_to_max_angle;
  servo.writeMicroseconds(duty_cycle_us);
}

void setup() {
  up_down_servo.attach(8);  // attaches the servo on pin 8 to the servo object
  up_down_servo.write(170); // Maximum is 170 and that's looking forward, and smallest is about 140 and that is looking a bit downwards

  left_right_servo.attach(9);  // attaches the servo on pin 9 to the servo object
  left_right_servo.write(170); // 155 is facing forward.  170 is looking to the left for him
  Serial.begin(115200);
  Serial.println("up_down, left_right");  // Output a CSV stream, showing the desired positions
}

void loop() {
  const float graduations = 1000.0;

  for (pos = 0; pos < graduations; pos++) {
    const float up_down_angle = 160+10*sin(pos / graduations * 2.0 * 3.1415);
    const float left_right_angle = 155+5*cos(pos / graduations * 2.0 * 3.1415);
    servoAccurateWrite(left_right_servo, left_right_angle);
    servoAccurateWrite(up_down_servo, up_down_angle);
    Serial.print(up_down_angle);
    Serial.print(",");
    Serial.println(left_right_angle);
    delay(15);
  }
}

And the result of the position, as reported by TrackIR:

trackir reported position against time xy with writeMicroseconds

What a huge difference this makes! This is much more smooth. It doesn’t look very sinusoidal, but it’s a lot smoother.

Wifi / bluetooth RSSI signal strength to distance

Imagine you have a bluetooth device somewhere in your house, and you want to try to locate it.  You have several other devices in the house that can see it, and so you want to triangulate its position.

This article is about the result I achieved, and the methodology.

I spent two solid weeks working on this, and this was the result:

RSSI Location of a single bluetooth device

Estimating the most probable position of a bluetooth device, based on 7 strength readings.

We are seeing a map, overlaid in blue by the most likely position of a lost bluetooth device.

And a more advanced example, this time with many different devices, and a more advanced algorithm (discussed further below).

Note that some of the devices have very large uncertainties in their position.

Liklihood estimation of many devices

Estimating position of multiple bluetooth devices, based on RSSI strength.

And to tie it all together, a mobile app:

Find It App Screen

Methodology

There are quite a few articles, video and books on estimating the distance of a bluetooth device (or wifi hub) based on knowing the RSSI signal strength readings.

But I couldn’t find any that gave the uncertainty of that estimation.

So here I derive it myself, using the Log-distance_path loss model

rssi = -10n \log_{10}(d) + A + Noise

In this model:

  •  rssi is the signal strength, measured in dB
  • n is a ‘path loss exponent’:
  • A is the rssi value at 1 meter away
  • Noise is Normally distributed, with mean 0 and variance σ²
  • d is our distance (above) or estimated distance (below)
Rearranging to get an estimated distance, we get:
d = 10^{\dfrac{A - rssi + Noise}{10n}}
Now Noise is sampled from a Normal distribution, with mean = 0 and variance = σ², so let’s write our estimated d as a random variable:
d \sim 10^{\dfrac{A - rssi + N(0,\sigma^2)}{10n}}
Important note: Note that random variable d is distributed as the probability of the rssi given the distance.  Not the probability of the distance given the rssi.  This is important, and it means that we need to at least renormalize the probabilities over all possible distances to make sure that they add up to 1.  See section at end for more details.
Adding a constant to a normal distribution just shifts the mean:
d \sim 10^{\dfrac{N(A - rssi,\sigma^2)}{10n}}
Now let’s have a bit of fun, by switching it to base e.  This isn’t actually necessary, but it makes it straightforward to match up with wikipedia’s formulas later, so:
d \sim e^{\dfrac{N(A - rssi,\sigma^2) \cdot \ln(10)}{10n}}
d \sim e^{N(A - rssi,\sigma^2)\cdot \ln(10)/10n}
d \sim \mathrm{Lognormal}(A - rssi,\sigma^2)^{\frac{\ln(10)}{10n}}
And we thus get our final result:
\boxed{d \sim \mathrm{Lognormal}((A - rssi)\cdot\ln(10)/(10n),\sigma^2\cdot\ln(10)^2/(10n)^2)}
rssi_plot

Distance in meters against probability density, for an rssi value of -80, A=-30, n=3, sigma^2=40

Bayes Theorem

I mentioned earlier:

Important note: Note that random variable d is distributed as the probability of the rssi given the distance.  Not the probability of the distance given the rssi.  This is important, and it means that we need to at least renormalize the probabilities over all possible distances to make sure that they add up to 1.  See section at end for more details.

So using the above graph as an example, say that our measured RSSI was -80 and the probability density for d = 40 meters is 2%.

This means:

P(measured_rssi = -80|distance=40m) = 2%

But we actually want to know is:

P(distance=40m | measured_rssi=-80)

So we need to apply Bayes theorem:


So we have an update rule of:

P(distance=40m | measured_rssi=-80) = P(measured_rssi = -80|distance=40m) * P(distance=40m)

Where we initially say that all distances within an area are equally likely =  P(distance=40m) = 1/area

And we renormalize the probability to ensure that sum of probabilities over all distances = 1.



Laplace Transform – visualized

The Laplace Transform is a particular tool that is used in mathematics, science, engineering and so on.  There are many books, web pages, and so on about it.

My animations are now on Wikipedia: https://en.wikipedia.org/wiki/Laplace_transform

And yet I cannot find a single decent visualization of it!  Not a single person that I can find appears to have tried to actually visualize what it is doing.  There are plenty of animations for the Fourier Transform like:

fourier

But nothing for Laplace Transform that I can find.

So, I will attempt to fill that gap.

What is the Laplace Transform?

It’s a way to represent a function that is 0 for time < 0 (typically) as a sum of many waves that look more like:

laplace

Graph of e^t cos(10t)

Note that what I just said isn’t entirely true, because there’s an imaginary component here too, and we’re actually integrating.  So take this as a crude idea just to get started, and let’s move onto the math to get a better idea:

Math

The goal of this is to visualize how the Laplace Transform works:

\displaystyle\mathscr{L}\{f(t)\}=F(s)

To do this, we need to look at the definition of the inverse Laplace Transform:

\displaystyle f(t) = \mathscr{L}^{-1}\{F(s)\}=\frac{1}{2\pi j}\int^{c+j\infty}_{c-j\infty} F(s)e^{st}\mathrm{d}s

While pretty, it’s not so nice to work with, so let’s make the substitution:

\displaystyle s := c+jr

so that our new limits are just \infty to -\infty, and \mathrm{d}s/\mathrm{d}r = j giving:

\displaystyle f(t) = \mathscr{L}^{-1}\{F(s)\}=\frac{1}{2\pi j}\int^{\infty}_{-\infty} F(c+jr)e^{(c+jr)t}j\mathrm{d}r

\displaystyle = \frac{1}{2\pi}\int^{\infty}_{-\infty} F(c+jr)e^{(c+jr)t}\mathrm{d}r

Which we will now approximate as:

\displaystyle \approx \frac{1}{2\pi}\sum^{n}_{i=-n} F(c+jr_i)e^{(c+jr_i)t}\Delta r_i

Code

The code turned out to be a bit too large for a blog post, so I’ve put it here:

https://github.com/johnflux/laplace-transform-visualized/blob/master/Laplace%20Transform.ipynb

Results

Note: The graphs say “Next frequency to add: … where s = c+rj“, but really it should be “Next two frequencies to add: … where s = c\pm rj” since we are adding two frequencies at a time, in such a way that their imaginary parts cancel out, allowing us to keep everything real in the plots.  I fixed this comment in the code, but didn’t want to rerender all the videos.

A cubic polynomial:

A cosine wave:

Now a square wave.  This has infinities going to infinity, so it’s not technically possible to plot.  But I tried anyway, and it seems to visually work:



Gibbs Phenomenon

Note the overshoot ‘ringing’ at the corners in the square wave. This is the Gibbs phenomenon and occurs in Fourier Transforms as well. See that link for more information.



Now some that it absolutely can’t handle, like: \delta(t).  (A function that is 0 everywhere, except a sharp peak at exactly time = 0).  In the S domain, this is a constant, meaning that we never converge.  But visually it’s still cool.

Note that this never ‘settles down’ (converges) because the frequency is constantly increasing while the magnitude remains constant.

There is visual ‘aliasing’ (like how a wheel can appear to go backwards as its speed increases). This is not “real” – it is an artifact of trying to render high frequency waves. If we rendered (and played back) the video at a higher resolution, the effect would disappear.

At the very end, it appears as if the wave is just about to converge. This is not a coincidence and it isn’t real. It happens because the frequency of the waves becomes too high so that we just don’t see them, making the line appear to go smooth, when in reality the waves are just too close together to see.

The code is automatically calculating this point and setting our time step such that it only breaksdown at the very end of the video. If make the timestep smaller, this effect would disappear.

And a simple step function:

A sawtooth:

Compiler is ignoring my C code!

Sometimes you come across a weird bug where the output seems to be completely impossible.  And it’s extremely hard to debug or search on google for, if you don’t know about this:

If your code has Undefined Behaviour, the compiler is allowed to assume it won’t happen, and can ‘optimize out’ chunks of your code.

Here’s a code snippet in a real bug I found yesterday:



#define FOO_SIZE 10
int foo2[FOO_SIZE];
...
int n=0;
do {
    p->foo[n] = foo2[n];
    n++;
} while( (foo2[n] != 0) && (n < FOO_SIZE) );
printk("n is %d\n", n);





This printed out:

   n is 165

and the system crashed.

But how can n become larger than FOO_SIZE=10 ?  Because the compiler ‘optimized’ away the check.  Here’s the asm:

} while( (foo2[n] != 0) && (n < FOO_SIZE) );
   21a14:       f813 2f01       ldrb.w  r2, [r3, #1]!
   21a18:       2a00            cmp     r2, #0
   21a1a:       d1f8            bne.n   21a0e <NV_Get+0x82>
   21a1c:       e7ca            b.n     219b4 <NV_Get+0x28>

What we are seeing here is that the “n < FOO_SIZE”  check has been completely removed by the compiler.  Why?

Because in the check, if n == FOO_SIZE, we would be checking if:  foo2[FOO_SIZE] != 0.  But this is out of bounds for foo.  The compiler knows that this is out of bounds, and so knows that this is undefined behaviour.  But the compiler is allowed to assume that undefined behaviour doesn’t happen, and so it assumes that n can NEVER be >= FOO_SIZE.  Thus it can remove the n < FOO_SIZE check.

This can be fixed by switching the order of the && like:

} while( (n < FOO_SIZE) && (foo2[n] != 0) );

Or, by checking n-1 instead  (which is slightly different behaviour, but good enough for me.  I was changing a lot of code with this bug.)

} while( (foo2[n-1] != 0) && (n < FOO_SIZE) );
   21a26:       7809            ldrb    r1, [r1, #0]
   21a28:       2900            cmp     r1, #0
   21a2a:       d0c3            beq.n   219b4 <NV_Get+0x28>
   21a2c:       429a            cmp     r2, r3
   21a2e:       d1f5            bne.n   21a1c <NV_Get+0x90>
   21a30:       e7c0            b.n     219b4 <NV_Get+0x28>

Now we see the second comparison in the asm.

Calibrating Cameras

It is common to want to calibrate cameras for lens distortion.



First print out a standard chequerboard image, and take some photos of it from various angles. You can print out images, for example, here:

https://calib.io/pages/camera-calibration-pattern-generator

Here I assume these photos are in camera_cal/calibration*.jpg

Even if you ultimately want to calibrate the images from c++, python, javascript etc, the calibration itself can be done separately, in a more convenient language, producing a matrix that you can use pretty much anywhere.  In my case, I calibrate in a jypter notebook, but use the matrix in c++.

%matplotlib inline

import numpy as np
import cv2
import glob
import matplotlib.pyplot as plt
#%matplotlib qt

# prepare object points, like (0,0,0), (1,0,0), (2,0,0) ....,(6,5,0)
objp = np.zeros((6*9,3), np.float32)
objp[:,:2] = np.mgrid[0:9,0:6].T.reshape(-1,2)

# Arrays to store object points and image points from all the images.
objpoints = [] # 3d points in real world space
imgpoints = [] # 2d points in image plane.

# Make a list of calibration images
images = glob.glob('camera_cal/calibration*.jpg')

# Step through the list and search for chessboard corners
for fname in images:
img = cv2.imread(fname)
gray = cv2.cvtColor(img,cv2.COLOR_BGR2GRAY)

# Find the chessboard corners
ret, corners = cv2.findChessboardCorners(gray, (9,6),None)

# If found, add object points, image points
if ret == True:
objpoints.append(objp)
imgpoints.append(corners)

# Draw and display the corners
img = cv2.drawChessboardCorners(img, (9,6), corners, ret)
plt.imshow(img)
plt.show()

ret, camera_undistort_matrix, camera_undistort_dist, rvecs, tvecs = cv2.calibrateCamera(objpoints, imgpoints, gray.shape[::-1], None, None)

fname = images[8]
img = cv2.imread(fname)
gray = cv2.cvtColor(img,cv2.COLOR_BGR2GRAY)
ret, corners = cv2.findChessboardCorners(gray, (9,6),None)
print(ret)
img = cv2.drawChessboardCorners(img, (9,6), corners, ret)
dst = cv2.undistort(img, camera_undistort_matrix, camera_undistort_dist, None, camera_undistort_matrix)
img = np.concatenate((img, dst), axis=1)
plt.imshow(img)
cv2.imwrite("output_images/undistort_chessboard.png", img)
plt.show()

output_2_1

On the left is the original photo, and on the right is after applying the undistortion matrix warp.

import pickle
with open('camera_undistort_matrix.pkl', 'wb') as f:
pickle.dump((camera_undistort_matrix, camera_undistort_dist), f)
print(camera_undistort_matrix)
[[ 1.15777829e+03 0.00000000e+00 6.67113865e+02]
[ 0.00000000e+00 1.15282230e+03 3.86124659e+02]
[ 0.00000000e+00 0.00000000e+00 1.00000000e+00]]



img = cv2.imread("test_images/straight_lines1.jpg")
dst = cv2.undistort(img, camera_undistort_matrix, dist, None, camera_undistort_matrix)
img = np.concatenate((img,dst),axis=1)
img_rgb = cv2.cvtColor(np.asarray(img), cv2.COLOR_BGR2RGB)
plt.imshow(img_rgb)
cv2.imwrite("output_images/undistort_straight_lines1.png", img)
plt.show()

In the top left is the original image, in the top right is the undistorted image.  There is little difference to the eye, but the distortion lets us to now apply further distortions such as a perspective transform to provide an apparent “top-down view”.

It is also useful for applying other transforms key to stitching together images from multiple cameras.
